There are several great official and community-supported containers for many programming languages, including Go, but these containers can be quite large. Let's walk through a comparison of methods for building containers for Go applications, then I'll show you a way to statically build Go apps for containerization that are extremely small.
Part One: Our "app"
We need something to test for our app, so let's make something pretty small: we're going to fetch google.com and output the size of the html we fetch:
package main
import (
"fmt"
"io/ioutil"
"net/http"
"os"
)
func main() {
resp, err := http.Get("https://google.com")
check(err)
body, err := ioutil.ReadAll(resp.Body)
check(err)
fmt.Println(len(body))
}
func check(err error) {
if err != nil {
fmt.Println(err)
os.Exit(1)
}
}If we run this, it will just print out some numbers. For me, it was around 17k. I purposefully decided to do something with SSL for reasons I promise to explain later.
Part 2: Dockerize
Following the official Docker image for Go, we would write an "onbuild" Dockerfile like this:
FROM golang:onbuild
The "onbuild" images assume your project structure is standard and will build your app like a generic Go app. If you want more control, you could use their standard Go base image and compile yourself:
FROM golang:latest RUN mkdir /app ADD . /app/ WORKDIR /app RUN go build -o main . CMD ["/app/main"]
This is nice if you have a Makefile or something else nonstandard you have to do when you're building your app. We could download some assets from a CDN or maybe add them in from another project, or maybe we want to run our tests within the container.
As you can see, Dockerizing Go apps is pretty straightforward, especially since we don't have any services or ports we need access to or to export. But there's one big drawback to the official images: they're really big. Let's take a look:
REPOSITORY SIZE TAG IMAGE ID CREATED VIRTUAL SIZE example-onbuild latest 9dfb1bbac2b8 19 minutes ago 520.7 MB example-golang latest 02e19291523e 19 minutes ago 520.7 MB golang onbuild 3be7ee2ec1ae 9 days ago 514.9 MB golang 1.4.2 121a93c90463 9 days ago 514.9 MB golang latest 121a93c90463 9 days ago 514.9 MB
The bases are 514.9MB and our app adds just 5.8MB to that. Wow. So for our compiled application we still need 514.9MB of dependencies? How did that happen?
The answer is that our app was compiled inside the container. That means the container needs Go installed, and that means it needs Go's dependencies, which means we need a package manager and really an entire OS. In fact, if you look at the Dockerfile for golang:1.4, it starts with Debian Jessie, installs the GCC compiler and some build tools, curls down Go, and installs it. So we pretty much have a whole Debian server and the Go toolkit just to run our tiny app. What can we do?
https://js.hscta.net/cta/current.js
hbspt.cta.load(1169977, '7ded21c4-e4fa-4c72-8e1a-1f2aa205947b', {});
Part 3: Compile!
The way to improve is to do something a little... off the beaten path. What we're going to do is compile Go in our working directory, then add the binary into the container. That means a simple docker build won't work. We need a multi-step container build:
go build -o main . docker build -t example-scratch -f Dockerfile.scratch .
And Dockerfile.scratch is simply:
FROM scratch ADD main / CMD ["/main"]
So what's scratch? Scratch is a special docker image that's empty. It's truly 0B:
REPOSITORY TAG IMAGE ID CREATED VIRTUAL SIZE example-scratch latest ca1ad50c9256 About a minute ago 5.60 MB scratch latest 511136ea3c5a 22 months ago 0 B
Also, our container is just that 5.6MB! Cool! But there's one problem:
$ docker run -it example-scratch no such file or directory
Huh? What does that mean? Took me a while to figure it out, but our Go binary is looking for libraries on the operating system it's running in. We compiled our app, but it still is dynamically linked to the libraries it needs to run (i.e., all the C libraries it binds to). Unfortunately, scratch is empty, so there are no libraries and no loadpath for it to look in. What we have to do is modify our build script to statically compile our app with all libraries built in:
CGO_ENABLED=0 GOOS=linux go build -a -installsuffix cgo -o main .
We're disabling cgo which gives us a static binary. We're also setting the OS to Linux (in case someone builds this on a Mac or Windows) and the -a flag means to rebuild all the packages we're using, which means all the imports will be rebuilt with cgo disabled. These settings changed in Go 1.4 but I found a workaround in a GitHub Issue. Now we have a static binary! Let's try it out:
$ docker run -it example-scratch Get https://google.com: x509: failed to load system roots and no roots provided
Great, now what? This is why I chose to use SSL in our example. This is a really common gotcha for this scenario: to make SSL requests, we need the SSL root certificates. So how do we add these to our container?
Depending on the operating system, these certificates can be in many different places. If you look at Go's x509 library, you can see all the locations where Go searches. For many Linux distributions, this is /etc/ssl/certs/ca-certificates.crt. So first, we'll copy the ca-certificates.crt from our machine (or a Linux VM or an online certificate provider) into our repository. Then we'll add an ADD to our Dockerfile to place this file where Go expects it:
FROM scratch ADD ca-certificates.crt /etc/ssl/certs/ ADD main / CMD ["/main"]
Now just rebuild our image and run it, and it works! Cool! Let's see how big our app is now:
REPOSITORY TAG IMAGE ID CREATED VIRTUAL SIZE example-scratch latest ca1ad50c9256 About a minute ago 6.12 MB example-onbuild latest 9dfb1bbac2b8 19 minutes ago 520.7 MB example-golang latest 02e19291523e 19 minutes ago 520.7 MB golang onbuild 3be7ee2ec1ae 9 days ago 514.9 MB golang 1.4.2 121a93c90463 9 days ago 514.9 MB golang latest 121a93c90463 9 days ago 514.9 MB scratch latest 511136ea3c5a 22 months ago 0 B
We've added a little more than half a meg (and most of this is from the static binary, not the root certs). This is a really nice little container -- it'll be really easy to push and pull between registries.
Conclusion
Our goal in this post was to whittle down the container size for a Go application. Go is special in that it can create a statically linked binary that fully contains the application. Other languages can do this, but certainly not all of them. If we were to apply this technique of reducing container size to other languages, it would depend on what their minimal requirements are. For example, a Java or JVM app could be compiled outside a container and then be injected into a container that only has a JVM (and its dependencies). This is at least smaller than a container with the JDK present.
I'm really looking forward to the strides the community makes in creating both minimal OSes for container guests, as well as aggressively trimming down the requirements for all kinds of languages. The great thing about the public Docker hub is these can be shared with everyone easily.
